Motherboard series

Tomahawk series

chipset

Intel B760

CPU support

Supports 13th and 12th generation Intel® CoreTM, Pentium® and Celeron® processors adapted to the motherboard’s LGA 1700 slot
(*Please visit Colorful’s official website www.colorful.cn for the latest processor support list)

memory support

Provides 2 DDR4 memory slots, supporting up to 64 GB memory capacity (single slot supports up to 32 GB capacity)
– supports DDR4-4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000 (OC)/3733(OC)/3600(OC)/3466(OC)/3200/3000/2933/2800/2666/2400/2133MHz memory – supports Intel® Extreme Memory
Profile (XMP) memory technology
– supports dual channel memory Technology
(*Please visit Colorful official website www.colorful.cn to check the latest memory compatibility list)

Storage interface

Supports a total of 2 M.2 slots and 4 SATA 6Gb/s hard disk interfaces, supports using SATA hard disk devices to create RAID 0, RAID 1, RAID 5, RAID 10 disk arrays – M.2_1 slot: supports 2242/2280
specifications M.2 SSD (PCIe 4.0 x4, CPU channel)
-M.2_2 slot: supports 2242/2280 specifications M.2 SSD (PCIe 4.0 x4/Optane, PCH channel)
(*For details on the steps to create a RAID disk array, please see Colorful Official BIOS User Guide)

Extension ports

Rear I/O interface:
-1 PS/2 interface
-2 USB 2.0 interfaces
-4 USB 3.2 Gen 1 Type-A interfaces
-1 DP 1.2 interface, supporting up to 4K 60Hz resolution
-1 HDMI 2.0 Interface, supporting up to 4K 60Hz resolution
– 1 2.5G network interface
– 3 audio interfaces (audio input/audio output/microphone)
Onboard device interface:
– 1 CPU fan pin
– 2 system fan pins
– 1 water cooling pump pin
– 1 USB 2.0 pin can expand 2 USB 2.0 Type-A interfaces
– 1 USB 3.2 Gen 1 pin can expand 2 USB 3.2 Gen 1 Type-A interfaces
– 2 5V 3- pin ARGB pin
– 1 front audio pin
– 1 front panel pin
– 1 speaker pin
– 1 ME write protect jumper
– 1 clear CMOS jumper
– 1 BIOS burner pin
-1 diagnostic card pin
-1 PS/2 wake-up control jumper

expansion slot

1 PCIe 4.0 x16 slot
1 PCIe 3.0 x1 slot

System BIOS

128M UEFI, supports multiple languages

Power management

Support S3, S4, network S5 wake-up, support scheduled boot and incoming call boot

Hardware monitoring

Controllable CPU fan speed, controllable system fan speed, CPU temperature monitoring, System temperature monitoring, and voltage monitoring of each group

Onboard network card

RTL8125 2.5G network card

Onboard sound card

5.1 channel sound card

Motherboard specifications

M-ATX form factor
240mm x 207mm
